Issue 4.3.C

IP Director Version 4.3 – User Manual – Part 3: Ingest and Play-Out

EVS Broadcast Equipment

160

Tags placed on the same field.

If several tags are defined on the same field, the information
displayed will appear together on the display separated by
commas. The order of the information will always be the same :
GPI first then Hide, Swap info or Mute.

Note

The Tag Information uses lines that are also used for
warning status messages by the XT server, if an XT
warning OSD like !Dsk etc, should be displayed on
those lines, they are not displayed if tag information

are displayed. In other words, tag information takes
priority over XT warning information.

ss:ff

GPI #2, Hide, Mute

ss:ff

G #2,Hide,1→3 3→3 5→5 7→7

2→4 4→4 6→6 8→8
