IP Director Version 4.3 – User Manual – Part 3: Ingest and Play-Out
EVS Broadcast Equipment Issue 4.3.C
101
5.3.4 H
OW TO
V
IEW
K
EY AND
F
ILL
A
SSOCIATIONS
To view Key and Fill associations, proceed as follows:
1.
Select the icon in the Database Explorer toolbar to
change the clip view.
2. Select Fill Key
Once selected, the Thumbnail and Key Thumbnail columns are
added in the Database Explorer.
If a Fill clip is associated with a Key clip, the corresponding key
thumbnail is displayed in the Key thumbnail column. If no key
clip is associated, no key thumbnail is displayed.
To narrow your search, select the Fill button to view Fill clips
only or the Key button to view Key clips only. To see both, select
the two buttons.
Note
The Fill Key button is not available with “Simple List”
and “Thumbnails View” options.
