300 C HAPTER 13: C ONFIGURING U SER E NCRYPTION
Figure 23 shows an example of a radio configured to provide static and
dynamic WEP encryption for non-WPA clients. The radio uses dynamically
generated keys to encrypt traffic for dynamic WEP clients. The radio also
encrypts traffic for static WEP clients whose keys match the keys
configured on the radio.
Figure 23 Encryption for Dynamic and Static WEP
User D
TKIP
WPA
User C
Static WEP
-Unicast key = a1b1c1d1e1
-Multicast key = a2b2c2d2e2
Non-WPA User B
Dynamic 40-bit WEP
WPA
User A
Dynamic WEP
Non-WPA
WPA disabled
Dynamic WEP enabled
Static WEP enabled
-Unicast key = a1b1c1d1e1
-Multicast key = a2b2c2d2e2
WX Switch
MAP
