248 C HAPTER 10: C ONFIGURING MAP A CCESS P OINTS
Table 21 lists the external antenna models you can use with these MAPs.
Table 22 lists the external antenna models you can use with the MP-620.
Specifying the External Antenna Model
To specify the external antenna model, use the following command:
set ap apnumber radio {1 | 2} antennatype
{ANT1060 | ANT1120 | ANT1180 |
ANT5060 | ANT5120 | ANT5180 | ANT7360
ANT-1360-OUT | ANT-5360-OUT | ANT-5060-OUT | ANT-5120-OUT |
ANT-7360-OUT | internal}
Table 21 MP-341, MP-352, MP-262 External Antenna Models
Beamwidth
Model Type Horizontal Vertical
ANT-5060
(ASTN6S)* 802.11a 60° 14°
ANT-5120
(ASTN6T) 802.11a 120° 14°
ANT-5180
(ASTN6H) 802.11a 180° 14°
ANT1060 802.11b/g 60° 65°
ANT1120 802.11b/g 120° 60°
ANT1180 802.11b/g 180° 40°
Table 22 MP-620 External Antenna Models
Model
Radio
Type
Gain (dBi)
Beamwidth
Horizontal Vertical
ANT-1360-OUT
(WA6202-ANT-8G)
*
* The numbers in parentheses are the numbers that appear on the antennas. The numbers
beginning ANT are the part numbers and are the numbers you specify when configuring
the MAP. To verify an external antenna’s model number, look for the number in
parentheses.
802.11b/g 8 360° 15°
ANT-5360-OUT
(WA5201M-ANT-8A-1) 802.11a 8 360° 12°
ANT-5060-OUT
(WA5201M-ANT-17A) 802.11a 17 60° 6°
ANT-5120-OUT
(WA5201M-ANT-14A) 802.11a 14 120° 6°
