About The XDC Power Supply
Front Panel
26 Operating Manual for XDC Series Power Supply
Table 1.1 Front Panel Functions
Key Functions
Voltage Setpoint Enter voltage
Current Setpoint Enter current
Output ON/OFF Toggle
Local/Remote Mode Toggle
Protection Set
OVP level
UVP level
OCP level
UCP level
OPP level
UPP level
Fold Mode Enter OV level
Enter UV level
Enter OC level
Enter UC level
Enter OP level
Enter UP level
Select fold mode
S/D if tripped?
S/D if tripped?
S/D if tripped?
S/D if tripped?
S/D if tripped?
Select fold delay Select Y or N
Select Y or N
Select Y or N
Select Y or N
Select Y or N
Read Alarms Read alarm msgs
Store User Setting Select 1 to 10
Recall
Factory default
Last setting
User setting
Auto sequence
Select 1 to 10
Select 1 to 10
Auto Sequence Operation (Run/Pause, Trigger, Stop)
MENU
Access menu functions
ENTER Make a selection
UP/DOWN Scroll to view selections, increment numerical entries
CE Clear entry
Numeric keypad Enter data
EXIT Cancel operation
Special Key Functions
UP View power readback (from default window)
CE Deletes a selected user setting from memory (Hold for 2 seconds)
EXIT Exit auto sequence
