Remote Operation
SCPI Commands for Digital Interfaces
Release 3.0 145
Table 4.9 OPERation Status Register
Bit Bit Weight Bit Name Description
0 1 CALibrating Indicates that the supply is in
CALibration Mode.
1 2 SETTling Not implemented
2 4 RANGing Not implemented
3 8 SWEeping Not implemented
4 16 MEASuring Not implemented
5 32 Waiting for TRIGger
Summary Indicates if the supply is waiting
for a TRIGger.
6 64 Waiting for ARM Summary Not implemented
7 128 CORRecting Not implemented
8 256 REGulating Summary Reflects the summary of the
REGulating Sub-Register.
9 512 SHUTdown Summary Reflects the summary of the
SHUTdown Sub-Register.
10 1024 Remote CONtrol
Summary Reflects the summary of the
Remote CONtrol Sub-Register.
11 2048 Current SHareSummary Reflects the summary of the
Current Share Sub-Register.
12 4096 Not Used Not used
13 8192 INSTrument Summary Not implemented
14 16384 PROGram Running Indicates that an Automated
Sequence is running.
15 32768 Not Used Not used
