Specifications and Characteristics
Electrical Specifications—Summary
Release 3.0 229
Table E.2Drift Specifications for 6000 Watt units (10V to 60V Models)
Models 10–600 20–300 30–200 40–150 60–100
Drift (30 minutes):
1
Voltage (0.04% of Vmax)
Current (0.6% of Imax)
1. Maximum drift over 30 minutes with constant line, load, and temperature, after power on.
4 mV
3600 mA 8 mV
1800 mA 12 mV
1200 mA 16 mV
900 mA 24 mV
600 mA
Drift (8 hours): 2
Voltage (0.02% of Vmax)
Current (0.04% of Imax)
2. Maximum drift over 8 hours with constant line, load, and temperature, after 30 minute warm-up.
2 mV
240 mA 4 mV
120 mA 6 mV
80 mA 8 mV
60 mA 12 mV
40 mA
Temperature Coefficient: 3
Voltage (0.04% of Vmax/°C)
Current (0.06% of Imax/°C)
3. Change in output per °C change in ambient temperature, with constant line and load.
4 mV
360 mA 8 mV
180 mA 12 mV
120 mA 16 mV
90 mA 24 mV
60 mA
