Page 203: Scpi com m an d refer ence scpi co mmand summary

SCPI Com

an
d Refer

ence

SCPI Co

mmand Summary

Release 3.0

Table B.3Commands for Output Control

Function

SCPI Command

Description

Query

Set (Immediate) Current
Setpoint

[[:]SOURce][]:CURRent[:LEVel][:IMMediate][:A
MPLitude] {|MAXimum|MINimum}

Change current setpoint

Yes

Set Triggered Current
Setpoint

[[:]SOURce][]:CURRent[:LEVel]:TRIGgered[:AMP
Litude] {|MAXimum|MINimum|DEFault}

Change triggered current setpoint

Yes

Set (Immediate) Power
Setpoint

[[:]SOURce][]:POWer[:LEVel][:IMMediate][:AMP
Litude] {|MAXimum|MINimum}

Change power setpoint

Yes

Set Triggered Power
Setpoint

[[:]SOURce][]:POWer[:LEVel]:TRIGgered[:AMPLi
tude] {|MAXimum|MINimum|DEFault}

Change triggered power setpoint

Yes

Set (Immediate)
Voltage Setpoint

[[:]SOURce][]:VOLTage[:LEVel][:IMMediate][:A
MPLitude] {|MAXimum|MINimum}

Change voltage setpoint

Yes

Set Triggered Voltage
Setpoint

[[:]SOURce][]:VOLTage[:LEVel]:TRIGgered[:AMP
Litude] {|MAXimum|MINimum|DEFault}

Change triggered votlage setpoint

Yes

Set Voltage Slew Rate
Voltage

[[:]SOURce][]:VOLTage:SLEW:STEP{ltage>|MAXimum|MINimum|DEFault}

Sets the voltage slew rate voltage change
for the programmed time interval

Yes

Set Voltage Slew Rate
Interval

[[:]SOURce][]:VOLTage:SLEW:INTerval{e-interval>|MAXimum|MINimum|DEFault}

Sets the voltage slew rate time interval for
the programmed voltage change

Yes

Set Over Current
Protection Level

[[:]SOURce][]:CURRent:PROTection[:OVER][:LEV
el] {|MAXimum|MINimum}

Set the over current protection level

Yes

Set Over Current
Protection
Shutdown State

[[:]SOURce][]:CURRent:PROTection[:OVER]:STAT
e

Select over current protection to
shutdown(ON) or set alarm (OFF)

Yes

Query Over Current
Protection Tripped

[[:]SOURce][]:CURRent:PROTection[:OVER]:TRIP
ped?

Query if over current protection mechanism
has tripped

N/A

Set Under Current
Protection Level

[[:]SOURce][]:CURRent:PROTection:UNDer[:LEVe
l] {|MAXimum|MINimum}

Set under current protection level

Yes

Set Under Current
Protection
Shutdown State

[[:]SOURce][]:CURRent:PROTection:UNDer:STATe

Select under current protection to shutdown
(ON) or set alarm (OFF)

Yes

Query Under Current
Protection Tripped

[[:]SOURce][]:CURRent:PROTection:UNDer:TRIPp
ed?

Query if under current protection
mechanism has tripped

N/A

Set Over Power
Protection Level

[SOURce][]:POWer:PROTection[:OVER][:LEVel]
{|MAXimum|MINimum}

Set the over power protection level

Yes

Set Over Power
Protection
Shutdown State

[SOURce][]:POWer:PROTection[:OVER]:STATe

Select over power protection to shutdown
(ON) or set alarm (OFF)

Yes

Query Over Power
Protection Tripped

[[:]SOURce][]:POWer:PROTection[:OVER]:TRIPpe
d?

Query if over power protection mechanism
has tripped

N/A

Set Under Power
Protection Level

[[:]SOURce][]:POWer:PROTection:UNDer[:LEVel]
{|MAXimum|MINimum}

Set under power protection level

Yes
