Gpib operation, Gpib connection, Table 4.7 – Xantrex Technology XDC User Manual
Page 122: Gpib pins
Remote Operation
GPIB Operation
120
Operating Manual for XDC Series Power Supply
GPIB Operation
GPIB
Connection
The GPIB port is a special GPIB female connector. Table 4.7 describes the pin
functions. Pin 12 is not used.
Table 4.7 GPIB Pins
Pin #
Function
1
D1
2
D2
3
D3
4
D4
5
EOI
6
DAV
7
NRFD
8
NDAC
9
IFC
10
SRQ
11
ATN
12
Not used
13
D5
14
D6
15
D7
16
D8
17
REN
18
Ground
19
Ground
20
Ground
21
Ground
22
Ground
23
Ground
24
Ground
