About The XDC Power Supply
Front Panel
Release 3.0
23
Figure 1.2 Front Panel (12000 Watt)
1. Rack mount brackets
2. Handles
3. On/Off switch
4. Air intake vents
5. Front panel display (vacuum fluorescent display). See Figure 1.4 for details.
6. Voltage knob
7. Current knob
8. Keypad. (See Figure 1.3 for details.)
1
2
3
4
5
6
7
8
1
2
