204

Operating Manual for

XDC Series Power Sup

ply

SCPI Command Re

rence

SCPI C

omman

d Summary

Table B.7Commands for Fold Protection

Table B.8Commands for Triggering

Table B.9System Commands

Function

SCPI Command

Description

Query

Set Output Fold Delay

[:]OUTPut[]:PROTection:FOLD:DELay

Set the delay time (seconds) before fold
protection is triggered.

Yes

Set Output Fold Mode

[:]OUTPut[]:PROTection:FOLD[:MODE]
{NONE|CC|CP|CV}

Select which regulation mode to fold back
(None,CV, CC, CP)

Yes

Query Fold Protection
Tripped

[:]OUTPut[]:PROTection:FOLD:TRIPped?

Query if fold protection has tripped

N/A

Function

SCPI Command

Description

Query

Set Immediate Initiation of
Trigger System

[:]INITiate[][:IMMediate]

Initiate a triggered event or sequence

N/A

Set Trigger Source

[:]TRIGger[][:SEQuence]:SOURce
{BUS|EXTernal|IMMediate|NONE}

Sets the trigger source for triggered
setpoints

Yes

Function

SCPI Command

Description

Query

Query System Error

[:]SYSTem[]:ERRor[:NEXT]?

Returns the next error in the instrument’s
error queue

N/A

Recall Default Factory
Preset

[:]SYSTem[]:RECall:DEFault

Restore the factory preset values

N/A

Select Remote Control
Source

[:]SYSTem[]:REMote:SOURce
{RS232|GPIB|AVOLtage|ACURrent|AVCurrent|MCHannel}

Select the remote control source

Yes

Set RS-232 Baud Rate

[:]SYSTem[]:COMMunicate:SERial[:RECeive]:BAU
D {1200|2400|4800|9600|…}

Configure the RS-232 baud rate

Yes

Set RS-232 Flow Control

[:]SYSTem[]:COMMunicate:SERial[:RECeive]:PAC
E {HARDware|XON|NONE}

Select type of flow control for RS-232

Yes

Set Multichannel Address
(6000 W only)

[:]SYSTem[]:COMMunicate:MCHannel:ADDRess

Select the multichannel unit address

Yes

Set GPIB Address

[:]SYSTem[]:COMMunicate:GPIB[:SELF]:ADDRess

Configure GPIB address

Yes

Set GPIB Power On
Service Request

[:]SYSTem[]:COMMunicate:GPIB[:SELF]:PONSrq
{ON|OFF|0|1}

Configure GPIB PON SRQ

Yes

Select Range for Analog
Programming Interface

[:]SYSTem[]:COMMunicate:APRogram:LEVel
{5|10}

Select analog interface voltage levels

Yes

Set Remote Control
Operation (Serial
Interface)

[:]SYSTem[]:REMote:STATe
{LOCal|REMote|RWLock}

RS-232 Only. Change remote control mode

Yes

Query SCPI Version

[:]SYSTem[]:VERSion?

Returns the SCPI version to which the
instrument complies. Format is YYYY.V

N/A
