6. System Design

MSAP2000 Technical Manual V3.0

6-2

Module Name

Subscriber
Qty/Card

Subscriber
Qty/Shelf

Subscriber Qty/System

FXS

16

256

1890 (STM-1) /
7560 (STM-4)

Non-Blocking

FXS-P 8 128 1024

(STM-1)/

Non-Blocking

2W/4W E&M

4

64

512 (STM-1) /

QE1M

4

63

63 (STM-1) /
252(STM-4)

GSH

1

16

63 (STM-1) /
252 (STM-4)

2Mbps per port

ETH 1

16

63

(STM-1)

2Mbps per port

CEoSM 1

16 63

(STM-1)

2Mbps per port

N64M 1 16 63

(STM-1)

2Mbps per port

LULT 4 64 512
AAM 12

96

756

(GbE

uplink)*

2Mbps per port

ESM 8 128

512(GbE

uplink)+

2Mbps per port

REoSM 8

128 128

*For xDSL services, the limitation of the ports per system will depend on the exact band-width

requirement. And there is a best effort method to increase the allowed port density. It is suggested

that user shall consult with

ZyXEL

support team to find out the best solution when the application is

clear

+ Similar to xDSL, the total ETHERNET port through ESM is also band-width dependent. Please

consult

ZyXEL

support team to find best solution for deployment.
