E&M Panel View
LED Status Description
ACTV (Green) Green: Functioning normally
OFF: CPU, or Power failure
FAIL (Red) ON: CPU, or auto-detection failure
OFF: Functioning normally
CH1 (Green) ON: Voice transmission in progress
in Channel 1
OFF: Channel is unoccupied
CH2 (Green)
CH3 (Green)
CH4 (Green) ON: Voice transmission in progress
in Channel 2
OFF: Channel is unoccupied
ON: Voice transmission in progress
in Channel 3
OFF: Channel is unoccupied
ON: Voice transmission in progress
in Channel 4
OFF: Channel is unoccupied
