7. Product Specification

MSAP2000 Technical Manual V3.0

7-58

7.21.

G.SHDSL Module (GSH)

Overview

The G.SHDSL Module (GSH) is a trunk or subscriber-end Module
which complies with ITU-T G.991.2 Standards. When used together
with the GSH-R CPE, GSH can provide the subscriber with E1, V.35 or
Ethernet services.

When installed at the RT end, the GSH Module provides long-loop
symmetrical / synchronized leased line services; the GSH will need a
corresponding Module at the COT end, to be able to connect to
Exchange facilities, for service provision.

GSH supports Activation/Pre-activation Sequences which comply with
ITU-T G.991.2 standards. Within 10 trial Start-ups, at least 6
Startups need to be completed within 60 seconds.

Features
And
Benefits

„ Panel LEDS indicate status, faults, alarms, and network

connections.

„ Complies with ITU-T G.994 and ITU-T G.991.2 Standards
„ Supports EOCs (Embedded Operations Channel) which comply to

ITU-T G.991.2 Standards

„ Bandwidth receive and transmission capability reaches up to 2.304

Mbps, maximum

„ Bandwidth allows for frequency width adjustment at 64 Kbps per

step

„ Use of non-volatile memory devices for performance data storage

Function Diagram
