7. Product Specification
MSAP2000 Technical Manual V3.0 7-87
ESM Specification
Microprocessor Winbond W90N740
Flash ROM Flash EPROM(1MB)
Hardware
RAM SRAM (2MB)
Ethernet Interface Module Capacity 8 Ports
Connector
Flow Control Wiring MDI, MDI-X
802.3x flow control
Package Size Up to 1536 bytes
Max. Transmission Speed 100 Mbps
Step Adjustment speed 64 kbps
Ethernet Switching
Functions IEEE 802.1d STP support
Static MAC address filtering
Limited number of MAC
Addresses per Port
IEEE 802.1p support
Port-based & tag-based (IEEE
802.1Q) VLAN support
GVRP (Dynamic VLAN) support
Broadcast Storm control
Input Power 5 VDC/2.4A
Power
Consumption 4W@25°C
Environment Operation Temperature and
0°C to +60°C
Humidity Up to 95% relative humidity
Storage Temperature and -10°C to +80°C
Humidity Up to 95% relative humidity
Height 213 ± 1mm
Width 18 ± 1mm
Depth 257 ± 1mm
Dimension
Weight 317 ± 2 g
EMI
CNS 13438 or CISPR 22
ESD
IEC 61000-4-2 Class 1
