5. System Configuration
MSAP2000 User Manual V3.0 5-11
5.9. 960 Lines System Configuration (STM-1)
Module
Quantity
COT RT
Module Qty
Module Qty
Shelf 4 Shelf 4
CoPSM 8 RtPSM 8
MPM 1 MPM 1
OIM 2 OIM 2
MLTM 1 MLTM 1
FXO 60 FXS 60
ELM 3 ELM
3
EPM 3 EPM 3
Slot
Allocation
COT RT
Extension Shelf Extension Shelf
Slot
No.
Main
Shelf
1 2 3
Main
Shelf
1 2 3
1 FXO FXO FXO FXO FXS FXS FXS FXS
2 FXO FXO FXO FXO FXS FXS FXS FXS
3 FXO FXO FXO FXO FXS FXS FXS FXS
4 FXO FXO FXO FXO FXS FXS FXS FXS
5 FXO FXO FXO FXO FXS FXS FXS FXS
6 FXO FXO FXO FXO FXS FXS FXS FXS
7 FXO FXO FXO FXO FXS FXS FXS FXS
8 FXO FXO FXO FXO FXS FXS FXS FXS
9 FXO FXO FXO FXO FXS FXS FXS FXS
10 FXO FXO FXO FXO FXS FXS FXS FXS
11 FXO FXO FXO FXO FXS FXS FXS FXS
12 FXO FXO FXO FXO FXS FXS FXS FXS
13 ELM FXO FXO FXO ELM FXS FXS FXS
14 ELM FXO FXO FXO ELM FXS FXS FXS
15 ELM FXO FXO FXO ELM FXS FXS FXS
16 MLTM FXO FXO FXO MLTM FXS FXS FXS
17 OIM OIM
18 OIM OM
19
20 MPM EPM EPM EPM MPM EPM EPM EPM
21 CoPSM CoPSM CoPSM CoPSM RtPSM RtPSM RtPSM RtPSM
22 CoPSM CoPSM CoPSM CoPSM RtPSM RtPSM RtPSM RtPSM
