5. System Configuration
MSAP2000 User Manual V3.0 5-8
5.6. 480 Lines A/B wire System Configuration (STM-1)
Module Quantity
COT RT
Module Qty Module Qty
Shelf 2 Shelf 2
CoPSM 4
RtPSM 4
MPM 1 MPM 1
OIM 2 OIM 2
MLTM 1
MLTM 1
FXO 30 FXS 30
ELM 1 ELM 1
EPM 1 EPM 1
Slot Allocation
COT RT Slot
No.
Main
Shelf
Extension
Shelf Main
Shelf
Extension
Shelf
1 FXO FXO FXS FXS
2 FXO FXO FXS FXS
3 FXO FXO FXS FXS
4 FXO FXO FXS FXS
5 FXO FXO FXS FXS
6 FXO FXO FXS FXS
7 FXO FXO FXS FXS
8 FXO FXO FXS FXS
9 FXO FXO FXS FXS
10 FXO FXO FXS FXS
11 FXO FXO FXS FXS
12 FXO FXO FXS FXS
13 FXO FXO FXS FXS
14 FXO FXO FXS FXS
15 ELM FXO ELM
FXS
16 MLTM FXO MLTM FXS
17 OIM OIM
18 OIM OM
19
20 MPM EPM MPM EPM
21 CoPSM CoPSM RtPSM RtPSM
22 CoPSM CoPSM RtPSM RtPSM
