5. System Configuration

MSAP2000 User Manual V3.0

5-3

5.2. Module Capacity

COT Side

Module

Slot
Number

Lines Note

FXS

1~ 16

16

POTS connecting subscriber’s
CPE

FXS-P 1~

16 8

Payphone

LULT

1~ 16

4

ISDN BRI for Line Terminal

FXO

1~ 16

16

POTS connecting to PSTN

FXO-P 1~

16 8

Payphone

LUNT

1~ 16

4

ISDN BRI for network Terminal

QE1M

1~ 16

4

V5.2, Non-V5, ISDN PRI
Grooming E1, Fractional E1,
Asynchronous E1

E&M

1~ 16

4

2W/4W (analog leased line)

ETH

1~ 16

1

Ethernet over TDM
(Proprietary)

CEoSM

1~16

1

Ethernet over SDH

REoSM

18

8

Ethernet over SDH with 8-port
switch

GbE

18

1

Gigabit Ethernet with 16 port
switch

OGS

18

4

Optical Gigabit Ethernet
Switch (used with SM4)

PVM

1 ~ 18

128/256

VoIP Gateway

AAM

1~ 16

12

ADSLG.Lite/G.dmt, ADSL2/2+

V5P

1~18

1890/7560

V5 protocol processing

N64M

1~16

1

V.35 interface leased line

V24M

1~16

1

V.24 interface leased line

GSH 1~16

1

G.SHDSL
