5. System Configuration

MSAP2000 User Manual V3.0

5-5

5.3. 120 Lines A/B wire System Configuration (STM-1)

Module Quantity

COT RT
Module Qty Module Qty
Shelf 1 Shelf 1
CoPSM 2

RtPSM 2

MPM 1 MPM 1
OIM 2 OIM 2
MLTM 1

MLTM 1

FXO 8 FXS 8



Slot Allocation

COT RT

Slot
No.

Main Shelf

Main Shelf

1 FXO

FXS

2 FXO

FXS

3 FXO

FXS

4 FXO

FXS

5 FXO

FXS

6 FXO

FXS

7 FXO

FXS

8 FXO

FXS

9

10

11

12

13

14

15

16 MLTM

MLTM

17 OIM

OIM

18 OIM

OIM

19

20 MPM

MPM

21 CoPSM RtPSM
22 CoPSM RtPSM
