5. System Configuration
MSAP2000 User Manual V3.0 5-14
5.11. 120 POTS + 24 ADSL System Configuration (STM-1)
Module
Quantity
COT Main Shelf RT Main Shelf
Module Qty Module Qty
Shelf 1 Shelf 1
CoPSM 2
RtPSM 2
MPM 1 MPM 1
OIM 2 OIM 2
MLTM 1
MLTM 1
FXO 8 FXS 8
CEoSM 1
REoSM 1
AAM 2
Slot Allocation
COT RT Slot
No.
Main
Shelf
Main
Shelf
1
2 AAM
3
4 AAM
5 FXO FXS
6 FXO FXS
7 FXO FXS
8 FXO FXS
9 FXO FXS
10 FXO FXS
11 FXO FXS
12 FXO FXS
13
14 MLTM MLTM
15 OIM OIM
16 OIM OIM
17
18 CEoSM REoSM
19
20 MPM MPM
21 CoPSM
RtPSM
22 CoPSM RtPSM
