2. System Architecture
MSAP2000 Technical Manual V3.0 2-15
2.12. Network Management System
OptiCore is a Network Management System (NMS) developed
solely by
ZyXEL , for the MSAP2000 System. The COT’s RJ-45
port provides connection to the NMS. Operators may use
OptiCore’s GUI (Graphical User Interface) to remotely operate
MSAP2000, and conduct various operation and management
functions. After the COT receives commands from OptiCore via
SNMP MIB, it will dispatch the commands to the various RTs, for
system management.
OptiCore
™ Features
„ Provides cross-platform functions, so that Server and Client
can retain compatibility, despite use of different operation
systems.
„ Provides individual operation interfaces, based on different
user authorization levels and administrative settings.
„ Provides a Network Management hierarchy structure.
„ Provides comprehensive functions for management of System
settings, performance, fault, maintenance and security.
„ Compatible with several Database Servers.
„ Compatible with various types of Java Application Servers,
with no need for additional Patch files.
„ Supports multi-languages. Text files can be uploaded and
easily translated.
System Platform
OptiCore
™’s design is based on Java Application Platform
design, and its function is to serve as a cross-platform,
multi-function NMS. The OptiCore
™ NMS platform can
simultaneously control 300 MSAP2000s, and provide
simultaneous access to up to 10 operators.
Telecommunication
Standards
Adapts SNMP V2c Telecommunication Standards. OptiCore
™
is compatible with SNMPV3, CORBA, TL1, and CMIP standards,
and employs FTP or TFTP to upload and download software and
parameters.
Graphical User
Interface (GUI)
Windows-based Graphical User interfaces (GUI) are developed
using JAVA, and the GUIs represent realistic and flexible
management tools, that can be easily recognized by any
subscriber. The GUI is basically a step-by-step guide, that can
lead operators through the MSAP product series, and help
Service Providers to save on extra training costs.
Database
All system parameters are stored within the database; the
administrator may make copies, and update or recover software
and parameters.
