5. System Configuration
MSAP2000 User Manual V3.0 5-7
5.5. 360 Lines A/B wire System Configuration (STM-1)
Module Quantity COT RT
Module Qty Module Qty
Shelf 2 Shelf 2
CoPSM 4
RtPSM 4
MPM 1 MPM 1
OIM 2 OIM 2
MLTM 1
MLTM 1
FXO 23 FXS 23
ELM 1 ELM 1
EPM 1 EPM 1
Slot
Allocation
COT RT Slot
No.
Main
Shelf
Extension
Shelf Main
Shelf
Extension
Shelf
1 FXO FXO FXS FXS
2 FXO FXO FXS FXS
3 FXO FXO FXS FXS
4 FXO FXO FXS FXS
5 FXO FXO FXS FXS
6 FXO FXO FXS FXS
7 FXO FXO FXS FXS
8 FXO FXO FXS FXS
9 FXO FXO FXS FXS
10 FXO FXS
11 FXO FXS
12 FXO FXS
13 FXO FXS
14 FXO FXS
15 ELM ELM
16 MLTM MLTM
17 OIM OIM
18 OIM OM
19
20 MPM EPM MPM EPM
21 CoPSM CoPSM RtPSM RtPSM
22 CoPSM CoPSM RtPSM RtPSM
