4. System Components
MSAP2000 Technical Manual V3.0 4-15
4.8. Subscriber End Facilities
GSHDSL Modem
(GSH-R)
The GSH Module (G.SHDSL Line Card) is installed in MSAP2000
RT, and connected to the Client end facility (G.SHDSL modem)
via 2-wire copper lines. The GSH Module provides three types of
Digital Leased Line Interfaces:
(1) ITU-T G.703 E1 Interface
(2) ITU-T V.35 Interface
(3) 10/100 Base-TX Ethernet Interface
E1 Interface
Complies with ITU-T G.703/G.704/G.706.
Please refer to Chapter 11 of this Manual for information on
technological details and interface parameters.
V.35 Interface
Supports N 64 Kbit/s subscriber data frequency. N=1~31.
Ethernet Interface
„ Provides 10Base-T and 100Base-TX Auto-Negotiation
Interfaces.
„ Complies with IEEE 802.3 Ethernet and IEEE 802.3u Fast
Ethernet standard regulations, and supports Full Duplex and
Half Duplex transmission. With Cat-5 UTP 10 copper cables,
its transmission distance can reach up to 100 meters.
„ Provides Rate Limiting functions for receiving and transmitting
data. The frequency range can be set to anywhere from 192
Kbit/s to 2048 Kbit/s (adjusted at 64 Kbit/s per step). The
final error rate is less than 10%.
„ Uses a RJ-45 Connector
ADSL Modem
The AAM (ADSL Access Modem) Module is installed in the
MSAP2000 RT. It provides a subscriber bandwidth access
interface by connecting to the subscriber’s ATU-R (ADSL modem)
via 2-wire copper lines.
