7. Product Specification
MSAP2000 Technical Manual V3.0 7-38
OIM Specification
Microprocessor Winbond W90N70
Flash Flash EPROM (1MB)
Hardware
RAM SDRAM (2MB)
Synchronization
Clock Output 8 kHz
Clock Input Optical Receiver
Optical Interface
Standard Bit Rate
Line Code
155.52 Mbps
Binary Non-return-to-zero
(NRZ) after scrambling
Frame ITU-T G.707 with VC4
Connector SC/FC
Transmission Standard ITU-T G.957 L-1.1 (S-1.1
selectable)
Optical Transmitter
(Complies with
ITU-T G.957) Wavelength
Max.RMS Width S-1.1(1261~1360nm)/
L-1.1(1280~1335nm)
7nm(S-1.1)/4nm(L-1.1)
Optical Source SLM/MLM
Max.-20 dbWidth 1nm(L-1.1 SLM)
Output power -8~-15dBm(S-1.1)/0dBm
Min.extinction ratio 8.2dB(S-1.1)/L-1.1(10dB)
Optical Receiver
(Complies with
ITU-T G.957 Wavelength
Min.reception power at BER
≤
10 -10
S-1.1(1261~1360nm)/
L-1.1(1280~1335nm)
- 28dBm(S-1.1)/ - 34dBm(L-1.1)
Min.Overload -8dBm(S-1.1/-10dBm(L-1.1)
Max.Optical Path penalty 1dB
Jitter and Wander ITU-T G.825
Power Input 5VDC/1.2A
Power
Consumption 3.5W@25°C
Environment Operation Temperature and 0°C to +60°C
Humidity Up to 95% relative humidity
Storage Temperature and -10°C to +80°C
Humidity Up to 95% relative humidity
Height 213 ± 1mm
Width 18 ± 1mm
Depth 257 ± 1mm
Dimension
Weight 305 ± 2 g
EMI
CNS 13438 or CISPR 22
ESD
IEC 61000-4-2 Class 1
