7. Product Specification
MSAP2000 Technical Manual V3.0 7-90
AAM Specification
Network processor Wintegra WIN717
Flash Flash EPROM (4MB)
Hardware
RAM SDRAM (64MB)
Uplink Ethernet Port
2-ports 100/1000BaseT
Compliance International standard ANSI T1.413 issue 2, ADSL2
ITU-T G.992.1,
ITU-T G.992.2,
ITU-T G.992.3,
ITU-T G.992.4,
ITU-T ADSL2+(G.992.5) and
ITU-T G.994.1.
Line specification Line Impedance 135 Ohm
ADSL2+ DS 24Mbps MAX
US 2.4Mbps MAX (Annex M.)
Network Function Switch Capacity Up to 16k MAC address
MAC address filtering
802.1p Priority Preservation
Spanning tree protocol
VLAN Port-based VLAN
Tag, untag VLAN per 802.1q
Support GVRP for uplink
Management Command Line Through LCT UI
Web Based Through In-Band Ethernet
Alarm System Health SYS and ALM LED
Power Input -48VDC/0.7A
Power
Consumption 19.2W@25°C (12 ports fully
loaded)
Environment Operation Temperature and 0°C to +60°C
Humidity Up to 95% relative humidity
Storage Temperature and -10°C to +80°C
Humidity Up to 95% relative humidity
Height 196 ± 1mm
Width 37 ± 1mm
Depth 257 ± 1mm
Dimension
Weight 740 ± 2 g
EMI
CNS 13438 or CISPR 22
ESD
IEC 61000-4-2 Class 1
