5. System Configuration
MSAP2000 User Manual V3.0 5-22
5.19. 900 POTS + 180 ADSL + 2 G.SHDSL NGN System
Configuration
Module
Quantity
COT Main Shelf RT Main Shelf
Module Qty Module Qty
Shelf 1 Shelf 5
CoPSM 2 CoPSM 2
MPM 1 RtPSM 8
OIM 2 MPM 1
PVM 1 OIM 2
CEoSM 2 MLTM 1
QE1M 1 FXS 57
ELM 4
EPM 4
REoSM 2
AAM 15
GSH/GSH-R 2
Slot
Allocation
COT RT Slot
No.
Shelf 1 Shelf 1 Shelf 2 Shelf 3 Shelf 4 Shelf 5
1 QE1M MLTM FXS FXS FXS FXS
2 AAM AAM FXS FXS FXS
3 GSH FXS FXS FXS FXS
4 AAM AAM FXS FXS FXS
5 GSH FXS FXS FXS FXS
6 AAM AAM FXS FXS FXS
7 ELM FXS FXS FXS FXS
8 AAM AAM FXS FXS FXS
9 ELM FXS FXS FXS FXS
10 AAM AAM FXS FXS FXS
11 ELM FXS FXS FXS FXS
12 AAM AAM FXS FXS FXS
13 ELM FXS FXS FXS FXS
14 CEoSM AAM AAM FXS FXS FXS
15 PVM OIM FXS FXS FXS FXS
16 OIM AAM FXS FXS FXS FXS
17 OIM OIM
18 CEoSM REoSM REoSM
19
20 MPM MPM EPM EPM EPM EPM
21 CoPSM
CoPSM RtPSM RtPSM RtPSM RtPSM
22 CoPSM CoPSM RtPSM RtPSM RtPSM RtPSM
