5. System Configuration
MSAP2000 User Manual V3.0 5-18
5.15. 480 POTS + 96 ADSL + 6 G.SHDSL V5 System
Configuration (STM-1)
Module
Quantity
COT Main Shelf RT Main Shelf
Module Qty Module Qty
Shelf 1 Shelf 3
CoPSM 2 CoPSM 2
MPM 1 RtPSM 4
OIM 2 MPM 1
V5P 1 OIM 2
QE1M 3 MLTM 1
CEoSM 1 FXS 30
ELM 2
EPM 2
REoSM 1
AAM 8
GSH 6
concentration 1:4
Slot
Allocation
COT RT Slot
No.
Shelf 1 Shelf 1 Shelf 2 Shelf 3
1 QE1M MLTM FXS FXS
2 AAM FXS FXS
3 GSH FXS FXS
4 AAM FXS FXS
5 QE1M GSH FXS FXS
6 QE1M AAM FXS FXS
7 GSH FXS FXS
8 AAM FXS FXS
9 GSH FXS FXS
10 AAM FXS FXS
11 ELM FXS FXS
12 AAM FXS FXS
13 ELM FXS FXS
14 AAM FXS FXS
15 V5P OIM GSH FXS
16 OIM AAM GSH FXS
17 OIM OIM
18 CEoSM REoSM
19
20 MPM MPM EPM EPM
21 CoPSM CoPSM RtPSM RtPSM
22 CoPSM CoPSM RtPSM RtPSM
