ZyXEL Communications Multi-service Access Platform MSAP2000 - Manual (Page 115)

7. Product Specification
MSAP2000 Technical Manual V3.0 7-8
CoPSM Specification
Minimum input voltage -36 VDC (-42VDC optional)
Recommended input voltage -48 VDC (for 4 x 12V Battery)
DC Input
Voltage
Maximum input voltage -72 VDC (-56VDC optional)
Non-isolated -48 V Max.5A, overcurrent protection
Isolated -48V Max.3A, overcurrent protection
Isolated +5V Max.25A,overcurrent protection
Efficiency Normally 82%, 75% at worst
DC Output
Voltage
0°C to +60°C
Operation Temperature and
Humidity
Up to 95% relative humidity
-10°C to +80°C
Storage Temperature and
Humidity
Up to 95% relative humidity
Environment
Specification
Height
196 ± 1mm
Width 483 ± 1mm
Depth 257 ± 1mm
Dimension
Weight 7010 ± 10 g
EMI
CNS 13438 or CISPR 22
ESD
IEC 61000-4-2 Class 1
