4. System Components

MSAP2000 Technical Manual V3.0

4-9

QE1M provides performance monitoring functions, and it will
generate Near and Far end performance parameters for the data it
collects, such as data for Error Second (ES), Severely Error
Second (SES), and Unavailable Second (US). The history data
will record the current ES, SES and UAS information, the ES, SES
and UAS information for the past 8 hours, and also the ES, SES
and UAS information for the past 7 days.

GbE

MSAP2000 provides one Gigabit Ethernet optic trunk interface
(GbE). Besides supporting various Protocols such as IEEE
802.3z, 802.1d, 802.1p, 802.1q, the GbE Module also collects
status, fault, alarms and performance information. The GbE
Module can connect the RT to Ethernet devices directly or serve
as the trunk interface between COT and RT when circuit
emulation for E1 is required, or it can serve as a trunk interface to
connect the COT and RT, to provide broadband services.

4.6. COT Network Interface Module

MSAP2000’s COT provides interfaces for PSTN, Digital Data
Networks, and IP Networks. Its modular design allows network
planning personnel to select the quantity and type of network
modules, based on their own individual requirements.

MSAP2000 can provide connection to PSTN interfaces via analog
2W interfaces (FXO) or V5.2 interfaces. Linkage to a Digital Data
Network is made via 2Mbps E1, and it also has a GbE interface for
connection to IP networks.

„ PSTN

Interfaces

y

FXO (POTS)

y

FXO-P (Payphone)

y

LUNT (ISDN BRI)

y

E1 (V5.2)

„ Analog Leased Line Network Interfaces

y

2W E&M

y

4W E&M

„ Digital Data Network (DDN) Interfaces

y

QE1M (Synchronous/Asynchronous E1, Fractional E1, ISDN
PRI)

y

N64M (Nx64 Kbps with ITU-T V.35 Interface)

„ Asynchronous Data network Interfaces

y

V24M (for computer asynchronous network like RS-232)

„ IP Network Interfaces

y

ETH (Fast Ethernet over TDM, using HDLC bit
encapsulation)

y

EoSM (Fast Ethernet over SDH, using GFP or X.85/86)

y

GbE (Gigabit Ethernet)

„ Next Generation Network Interfaces for Soft-switch

y

PVM (Packet Voice Module integrates VoIP Gateway with
SIP, H.248 and MGCP)

FXO

The FXO Module is normally installed within the COT Shelf, and it
provides 16 lines of 2-wire analog voice interfaces for connection
to PSTN Exchange Stations. The functions of FXO include Dial
Ring Detection, Busy tone detection, ringing tone detection, Loop
