5. System Configuration
MSAP2000 User Manual V3.0 5-6
5.4. 240 Lines A/B wire System Configuration (STM-1)
Module Quantity
COT RT
Module Qty Module Qty
Shelf 1 Shelf 1
CoPSM 2
RtPSM 2
MPM 1 MPM 1
OIM 2 OIM 2
MLTM 1
MLTM 1
FXO 15 FXS 15
Slot Allocation
COT RT Slot
No.
Main Shelf Main Shelf
1 FXO FXS
2 FXO FXS
3 FXO FXS
4 FXO FXS
5 FXO FXS
6 FXO FXS
7 FXO FXS
8 FXO FXS
9 FXO FXS
10 FXO FXS
11 FXO FXS
12 FXO FXS
13 FXO FXS
14 FXO FXS
15 FXO FXS
16 MLTM MLTM
17 OIM OIM
18 OIM OIM
19
20 MPM MPM
21 CoPSM RtPSM
22 CoPSM RtPSM
