5. System Configuration
MSAP2000 User Manual V3.0 5-17
5.14. 480 POTS + 96 ADSL V5 System Configuration (STM-1)
Module
Quantity
COT Main Shelf RT Main Shelf
Module Qty Module Qty
Shelf 1 Shelf 3
CoPSM 2 RtPSM 6
MPM 1 MPM 1
OIM 2 OIM 2
V5P 1 MLTM 1
QE1M 1 FXS 30
CEoSM 1 ELM 2
EPM 2
REoSM 1
AAM 8
concentration 1:4
Slot
Allocation
COT RT Slot
No.
Shelf 1 Shelf 1 Shelf 2 Shelf 3
1 QE1M MLTM FXS FXS
2 AAM FXS FXS
3 FXS FXS
4 AAM FXS FXS
5 FXS FXS
6 AAM FXS FXS
7 FXS FXS
8 AAM FXS FXS
9 FXS FXS
10 AAM FXS FXS
11 FXS FXS
12 AAM FXS FXS
13 ELM FXS FXS
14 AAM FXS FXS
15 V5P OIM FXS
16 OIM AAM FXS
17 OIM OIM
18 CEoSM REoSM
19
20 MPM MPM EPM EPM
21 CoPSM RtPSM RtPSM RtPSM
22 CoPSM RtPSM RtPSM RtPSM
