5. System Configuration
MSAP2000 User Manual V3.0 5-21
5.18. 480 POTS + 180 ADSL NGN System Configuration
Module
Quantity
COT Main Shelf RT Main Shelf
Module Qty Module Qty
Shelf 1 Shelf 3
CoPSM 2 RtPSM 6
MPM 1 MPM 1
OIM 2 OIM 2
PVM 1 MLTM 1
CEoSM 2 FXS 30
ELM 2
EPM 2
REoSM 2
AAM 15
Slot
Allocation
COT RT Slot
No.
Shelf 1 Shelf 1 Shelf 2 Shelf 3
1 MLTM FXS FXS
2 AAM AAM FXS
3 FXS FXS FXS
4 AAM AAM FXS
5 FXS FXS FXS
6 AAM AAM FXS
7 FXS FXS FXS
8 AAM AAM FXS
9 FXS FXS FXS
10 AAM AAM FXS
11 FXS FXS FXS
12 AAM AAM FXS
13 ELM FXS FXS
14 CEoSM AAM AAM FXS
15 PVM OIM FXS FXS
16 OIM AAM FXS FXS
17 OIM OIM
18 CEoSM REoSM REoSM
19
20 MPM MPM EPM EPM
21 CoPSM RtPSM RtPSM RtPSM
22 CoPSM RtPSM RtPSM RtPSM
