7. Product Specification

MSAP2000 Technical Manual V3.0

7-5

Shelf Specification

DC Input

2 (3-pin EURO-TYPE)

External Clock Input

2 (2-pin wire-wrap posts)

Clock Output

1 (2-pin wire-wrap posts)

Alarm Input

5 (wire-wrap posts)

Alarm Output

7 (wire-wrap posts)


Input Terminal

Electrical Testing Interface

2

Power Supply Module

2 (Slots 21, 22)

Main Processing Module

2 (Slots 19, 20)

Special Module

2 (Slots 17, 18)

Service Module

16 (Slots 1 ~ 16)

Module Slot

100Mbps Full-Duplex Ethernet

16 (3.2 Gbps)

19.44 Mbps Telecom Bus

2 (311.04 Mbps)

16.384 Mbps PCM Highway

6 (98.304 Mbps)

Bandwidth

0°C to +60°C

Operation Temperature and
Humidity

Up to 95% relative humidity
(non-coagulating)
-10°C to +80°C

Storage Temperature and
Humidity

Up to 95% relative humidity
(non-coagulating)

Environment
Specification


Height

196 ± 1mm

Width

483 ± 1mm

Depth

275 ± 1mm

Dimension

Environmental
Compliance

ETSI

ETR 300 119

Weight

7010 ± 10 g


Mounting Method

19” / 23” rack mount


EMI

CNS 13438 or CISPR 22
