7. Product Specification
MSAP2000 Technical Manual V3.0 7-17
ELM Specification
Microprocessor Winbond W90N740
Flash ROM Flash EPROM (1MB)
Hardware
RAM SDRAM (2MB)
Optical Interface
Standard Bit Rate
Line Code
155.52 Mbps
Binary Non-return-to-zero
(NRZ) after scrambling
Frame ITU-T G.707 with VC4
Connector SC
Optical Transmitter
Wavelength
Optical Source
Output power 1310nm
FP Laser
-14dBm ~ -20dBm
Optical Receiver
Wavelength
Min.reception power at BER
≤
10-10
1260~1360nm
- 32dBm
Power Input 5VDC/1.2A
Power
Consumption 3W@25°C
Environment Operation Temperature and
0°C to +60°C
Humidity Up to 95% relative humidity
Storage Temperature and -10°C to +80°C
Humidity Up to 95% relative humidity
Height 213 ± 1mm
Width 18 ± 1mm
Depth 257 ± 1mm
Dimension
Weight 305 ± 2 g
EMI
CNS 13438 or CISPR 22
ESD
IEC 61000-4-2 Class 1
