5. System Configuration
MSAP2000 User Manual V3.0 5-15
5.12. 240 POTS + 48 ADSL System Configuration (STM-1)
Module
Quantity
COT Main Shelf RT Main Shelf
Module Qty Module Qty
Shelf 2 Shelf 2
CoPSM 4 RtPSM 4
MPM 1 MPM 1
OIM 2 OIM 2
MLTM 1 MLTM 1
FXO 15 FXS 15
ELM 1 ELM
1
EPM 1 EPM 1
CEoSM 1 REoSM 1
AAM 4
Slot
Allocation
COT RT
Extension Shelf Extension Shelf
Slot
No.
Main Shelf
1
Main Shelf
1
1 FXO FXS
2 FXO AAM FXS
3 FXO FXS
4 FXO AAM FXS
5 FXO FXS
6 FXO AAM FXS
7 FXO FXS
8 FXO AAM FXS
9 FXO FXS
10 FXO FXS
11 FXO FXS
12 FXO FXS
13 ELM FXO ELM FXS
14 MLTM FXO MLTM FXS
15 OIM FXO OIM FXS
16 OIM OIM
17
18 CEoSM REoSM
19
20 MPM EPM MPM EPM
21 CoPSM CoPSM RtPSM RtPSM
22 CoPSM CoPSM RtPSM RtPSM
