5. System Configuration
MSAP2000 User Manual V3.0 5-16
5.13. 360 POTS + 72 ADSL System Configuration (STM-1)
Module
Quantity
COT Main Shelf RT Main Shelf
Module Qty Module Qty
Shelf 2 Shelf 2
CoPSM 4 RtPSM 4
MPM 1 MPM 1
OIM 2 OIM 2
MLTM 1 MLTM 1
FXO 23 FXS 23
ELM 1 ELM
1
EPM 1 EPM 1
CEoSM 1 REoSM 1
AAM 6
Slot
Allocation
COT RT
Extension
Shelf Extension
Shelf
Slot
No.
Main
Shelf
1
Main
Shelf
1
1 FXO FXO FXS FXS
2 FXO FXO AAM FXS
3 FXO FXO FXS FXS
4 FXO FXO AAM FXS
5 FXO FXO FXS FXS
6 FXO FXO AAM FXS
7 FXO FXO FXS FXS
8
FXO AAM FXS
9 FXO FXS FXS
10 FXO AAM FXS
11 FXO FXS FXS
12 ELM FXO AAM FXS
13 ELM FXO FXS FXS
14 MLTM FXO ELM FXS
15 OIM FXO MLTM FXS
16 OIM FXO OIM FXS
17 OIM
18 CEoSM REoSM
19
20 MPM EPM MPM EPM
21 CoPSM CoPSM RtPSM RtPSM
22 CoPSM CoPSM RtPSM RtPSM
