4. System Components
MSAP2000 Technical Manual V3.0 4-12
4.7. Subscriber Interface Module
MSAP2000 is a broadband network access platform, with
integrated functions that can satisfy all customer needs. Its
subscriber interfaces include:
Analog Voice Interfaces: FXS (POT), FXS-P (Payphones), 2W/4W
E&M.
Digital Leased Line Interfaces: ISDN BRA/PRA, Nx64 Kbps, E1,
SDSL and G.SHDSL.
xDSL Interfaces: ADSL G.LITE, G.DMT, ADSL2/2+, and
G.SHDSL
Ethernet Interfaces: 10/100 Ethernet.
„ Analog Voice Interfaces:
y
FXS (POTS)
y
FXS-P (Payphones)
„ ISDN Interfaces
y
LUNT (ISDN BRI)
y
QE1M (ISDN PRI)
„ Analog Leased Line Interfaces
y
2W E&M
y
4W E&M
„ Digital Data Network Interfaces
y
QE1M (ITU-G G.703 Full E1 Fractional E1 Asynchronous
E1)
y
N64M (Nx64 Kbps with ITU-T V.35 Interface)
y
GSH (HDSL, G.SHDSL with Nx64 Kbps N=1~36)
„ IP Network Interfaces
y
ETH (Ethernet over TDM)
y
ESM (8-Port Ethernet Switch)
„ xDSL Interfaces
y
AAM (ADSL G.dmt G.Lite ADSL2 ADSL2+
„ High Speed Data Interfaces
y
STM -1 Electrical Interface (In SM1)
FXS
FXS provides 16 POTS interfaces. It supports DP (Dial Pulse)
and DTMF (Dual Tone Multiple Frequency) dialing modes, and it
adapts ITU-T G.711 standard A-law Companding coding rules and
CAS (Channel Associated Signaling). Its Link Performance
conforms to ITU-T G.712 standards as well as Chunghwa
Telecom’s ME 2401-4 Specifications. With no concentration or
compression, the maximum number of subscriber ports in one
shelf is 256. The maximum number of subscriber lines in one
system, without having to consider concentration or compression
is 1,890, while the number can increase to 7,560 with
concentration or compression.
FXS-P
The FXS-P Module is usually installed within the RT Shelf, and
