Chapter 2 Introducing the Web Configurator
NBG410W3G Series User’s Guide
54
2.4.5 Port Statistics
Click Port Statistics in the HOME screen. Read-only information here includes port status
and packet specific statistics. The Automatic Refresh Interval field is configurable.
REMOTE
MGMT
WWW Use this screen to configure through which interface(s) and from
which IP address(es) users can use HTTPS or HTTP to manage
the ZyXEL Device.
SSH Use this screen to configure through which interface(s) and from
which IP address(es) users can use Secure Shell to manage the
ZyXEL Device.
TELNET Use this screen to configure through which interface(s) and from
which IP address(es) users can use Telnet to manage the ZyXEL
Device.
FTP Use this screen to configure through which interface(s) and from
which IP address(es) users can use FTP to access the ZyXEL
Device.
SNMP Use this screen to configure your ZyXEL Device’s settings for
Simple Network Management Protocol management.
DNS Use this screen to configure through which interface(s) and from
which IP address(es) users can send DNS queries to the ZyXEL
Device.
CNM Use this screen to configure and allow your ZyXEL Device to be
managed by the Vantage CNM server.
UPnP UPnP Use this screen to enable UPnP on the ZyXEL Device.
Ports Use this screen to view the NAT port mapping rules that UPnP
creates on the ZyXEL Device.
Custom APP Custom APP Use this screen to specify port numbers for the ZyXEL Device to
monitor for FTP, HTTP, SMTP, POP3, H323, and SIP traffic.
ALG ALG Use this screen to allow certain applications to pass through the
ZyXEL Device.
LOGS View Log Use this screen to view the logs for the categories that you
selected.
Log Settings Use this screen to change your ZyXEL Device’s log settings.
Reports Use this screen to have the ZyXEL Device record and display the
network usage reports.
MAINTENANCE General This screen contains administrative.
Password Use this screen to change your password.
Time and Date Use this screen to change your ZyXEL Device’s time and date.
F/W Upload Use this screen to upload firmware to your ZyXEL Device
Backup &
Restore
Use this screen to backup and restore the configuration or reset
the factory defaults to your ZyXEL Device.
Restart This screen allows you to reboot the ZyXEL Device without turning
the power off.
LOGOUT Click this label to exit the web configurator.
Table 5 Screens Summary (continued)
LINK TAB FUNCTION
