Chapter 15 Remote Management
NBG410W3G Series User’s Guide
279
Figure 178 ADVANCED > REMOTE MGMT > CNM
The following table describes the labels in this screen.
Table 83 ADVANCED > REMOTE MGMT > CNM
LABEL DESCRIPTION
Registration
Information
Registration Status This read only field displays Not Registered when Enable is not selected.
It displays Registering when the ZyXEL Device first connects with the
Vantage CNM server and then Registered after it has been successfully
registered with the Vantage CNM server. It will continue to display
Registering until it successfully registers with the Vantage CNM server. It will
not be able to register with the Vantage CNM server if:
The Vantage CNM server is down.
The Vantage CNM server IP address is incorrect.
The Vantage CNM server is behind a NAT router or firewall that does not
forward packets through to the Vantage CNM server.
The encryption algorithms and/or encryption keys do not match between the
ZyXEL Device and the Vantage CNM server.
Last Registration Time This field displays the last date (year-month-date) and time (hours-minutes-
seconds) that the ZyXEL Device registered with the Vantage CNM server. It
displays all zeroes if it has not yet registered with the Vantage CNM server.
Refresh Click Refresh to update the registration status and last registration time.
Vantage CNM Setup
Enable Select this check box to allow Vantage CNM to manage your ZyXEL Device.
Vantage CNM Server
Address
If the Vantage server is on the same subnet as the ZyXEL Device, enter the
private or public IP address of the Vantage server.
If the Vantage CNM server is on a different subnet to the ZyXEL Device, enter
the public IP address of the Vantage server.
If the Vantage CNM server is on a different subnet to the ZyXEL Device and is
behind a NAT router, enter the WAN IP address of the NAT router here.
