Chapter 8 Wi-Fi
NBG410W3G Series User’s Guide
157
Figure 90 WIRELESS > Wi-Fi > Security: WEP
The following table describes the labels in this screen.
8.4.3 IEEE 802.1x Only
Click the WIRELESS > Wi-Fi > Security > Edit. Select 8021X-Only from the Security
Mode list.
Table 34 WIRELESS > Wi-Fi > Security: WEP
LABEL DESCRIPTION
Name Type a name to identify this security profile.
Security Mode Select WEP from the drop-down list.
WEP
Encryption
WEP (Wired Equivalent Privacy) provides data encryption to prevent unauthorized
wireless stations from accessing data transmitted over the wireless network.
Select 64-bit WEP, 128-bit WEP or 152-bit WEP to enable data encryption.
Authentication
Method
Select Shared-Key to have the ZyXEL Device use the default WEP key to
authenticate the wireless client to the ZyXEL Device.
Select Auto to have the ZyXEL Device switch between the shared-key and open
system (the wireless clients and AP do not share a secret key for authentication)
modes automatically.
The default setting is Auto.
Key 1 to Key 4 The WEP keys are used to encrypt data. Both the ZyXEL Device and the wireless
clients must use the same WEP key for data transmission.
If you chose 64-bit WEP in the WEP Encryption field, then enter any 5 ASCII
characters or 10 hexadecimal characters ("0-9", "A-F") preceded by 0x for each key.
If you chose 128-bit WEP in the WEP Encryption field, then enter 13 ASCII
characters or 26 hexadecimal characters ("0-9", "A-F") preceded by 0x for each key.
If you chose 152-bit WEP in the WEP Encryption field, then enter 16 ASCII
characters or 32 hexadecimal characters ("0-9", "A-F") preceded by 0x for each key.
You can configure up to four keys, but only one key can be activated at any one time.
The default key is key 1.
Apply Click Apply to save your customized settings and exit this screen.
Cancel Click Cancel to exit this screen without saving.
