Chapter 2 Introducing the Web Configurator

NBG410W3G Series User’s Guide

New PIN Code

Configure a PIN code for the SIM card. You can specify any four to eight digits to

have a new PIN code or enter the previous PIN code.

Confirm New PIN

Code

Enter the PIN code again for confirmation.

Apply

Click Apply to save your changes in this section.

Reset budget

counters, resume

budget control

This field displays if you have enabled budget control but insert a 3G card with a

different user account from the one for which you configured budget control.
Select this option to have the ZyXEL Device do budget calculation starting from 0

but use the previous settings.

Resume budget

control

This field displays if you have enabled budget control but insert a 3G card with a

different user account from the one for which you configured budget control.
Select this option to have the ZyXEL Device keep the existing statistics and

continue counting.

Disable budget

control

This field displays if you have enabled budget control but insert a 3G card with a

different user account from the one for which you configured budget control.
Select this option to disable budget control.
If you want to enable and configure new budget control settings for the new user

account, go to the 3G (WAN 2) screen.
The ZyXEL Device keeps the existing statistics if you do not change the budget

control settings. You could reinsert the original card and enable budget control to

have the ZyXEL Device continue counting the budget control statistics.

Apply

Click Apply to save your changes in this section.

Enter modem

unlock code

This field only displays when you insert a 3G card and the internal modem on the

3G card is blocked.
Enter a key to enable the internal modem on your 3G card. By default, the key is

the last four digits of your phone number used to dial up the 3G connection.

Otherwise, you need to get the key from your service provider.

Apply

Click Apply to save your changes in this section.

Remaining Time

Budget

This field is available only when you enable budget control in the 3G (WAN 2)

screen.
This shows the amount of time (in hours and minutes) the 3G connection can still

be used before the ZyXEL Device takes the actions you specified in the 3G (WAN

2) screen.

Remaining Data

Budget

This field is available only when you enable budget control in the Network > WAN

> 3G (WAN 2) screen.
This shows how much data (in bytes) can still be transmitted through the 3G

connection before the ZyXEL Device takes the actions you specified in the 3G

(WAN 2) screen.

Note: The budget counters will not be reset when you restore the

factory defaults. The budget counters are saved to the flash
every hour or when the 3G connection is dropped. If you
restart the ZyXEL Device within one hour, any change in the
counters will not be saved.

Reset time and

data budget

counters

This button is available only when you enable budget control in the 3G (WAN 2)

screen.
Click this button to reset the time and data budgets. The count starts over with the

3G connection’s full configured monthly time and data budgets. This does not

affect the normal monthly budget restart.

Table 4 Web Configurator HOME Screen (continued)

LABEL

DESCRIPTION
