NBG410W3G Series User’s Guide
345
C
H A P T E R
22
Product Specifications
This chapter gives details about your ZyXEL Device’s hardware and firmware features.
22.1 General ZyXEL Device Specifications
The following tables summarize the ZyXEL Device’s hardware and firmware features.
Table 119 Hardware Specifications
Dimensions 190 (W) x 150 (D) x 33 (H) mm
Weight 380 g
Power Specification 12V DC 1.5 A
Ethernet Interface
LAN/DMZ Four LAN/DMZ auto-negotiating, auto MDI/MDI-X 10/100 Mbps RJ-45
Ethernet ports.
WAN One auto-negotiating, auto MDI/MDI-X 10/100 Mbps RJ-45 Ethernet port.
Reset Button Restores factory default settings.
Internal 3G module SierraWireless MC8775 (NBG410W3G only)
USB slot The USB port is reserved for future usage. It cannot transmit signals
simultaneously with the internal 3G module.
SIM Card Slot For installing a 3G SIM card (NBG410W3G only).
Antenna NBG410W3G:
One internal 3.6 dBi antenna
One external 850/900/1800/1900/2100 MHz 3G antenna
NBG412W3G:
One external 3.6 dBi antenna
Distance between the
centers of the holes (for
wall mounting) on the
device’s back.
165.75 mm
Screw size for wall-
mounting
M 4*10 Tap Screw, see Figure 210 on page 348 .
Operation Environment Temperature: 0º C ~ 40º C
Humidity: 20% ~ 95% (non-condensing)
Storage Environment Temperature: -30º ~ 60º C
Humidity: 20% ~ 95% RH (non-condensing)
Certifications EMC: FCC Part 15 Class B, CE-EMC Class B, C-Tick Class B
Safety: CSA International, (UL60950-1, CSA60950-1, EN60950-1,
IEC60950-1)
