Chapter 2 Introducing the Web Configurator
NBG410W3G Series User’s Guide
52
2.4.4 Navigation Panel
After you enter the password, use the sub-menus on the navigation panel to configure ZyXEL
Device features.
The following table describes the sub-menus.
Latest Alerts This table displays the five most recent alerts recorded by the ZyXEL Device. You
can see more information in the View Log screen, such as the source and
destination IP addresses and port numbers of the incoming packets.
Date/Time This is the date and time the alert was recorded.
Message This is the reason for the alert.
System Status
Port Statistics Click Port Statistics to see router performance statistics such as the number of
packets sent and number of packets received for each port.
DHCP Table Click DHCP Table to show current DHCP client information.
Bandwidth Click Bandwidth to view the ZyXEL Device’s bandwidth usage and allotments.
Table 4 Web Configurator HOME Screen (continued)
LABEL DESCRIPTION
Table 5 Screens Summary
LINK TAB FUNCTION
HOME This screen shows the ZyXEL Device’s general device and
network status information. Use this screen to access the wizards,
statistics and DHCP table.
NETWORK
LAN LAN Use this screen to configure LAN DHCP and TCP/IP settings.
Static DHCP Use this screen to assign fixed IP addresses on the LAN.
IP Alias Use this screen to partition your LAN interface into subnets.
Port Roles Use this screen to change the LAN/DMZ port roles.
WAN General This screen allows you to configure operation mode, route priority
and connection test.
WAN1 Use this screen to configure the WAN1 connection for Internet
access.
3G (WAN2) Use this screen to configure the WAN2 connection for Internet
access.
Traffic
Redirect
Use this screen to configure your traffic redirect properties and
parameters.
DMZ DMZ Use this screen to configure your DMZ connection.
Static DHCP Use this screen to assign fixed IP addresses on the DMZ.
IP Alias Use this screen to partition your DMZ interface into subnets.
Port Roles Use this screen to change the LAN/DMZ port roles on the ZyXEL
Device.
WIRELESS
3G (WAN2) 3G (WAN2) Use this screen to configure the WAN2 connection for Internet
access.
