Chapter 22 Product Specifications
NBG410W3G Series User’s Guide
347
22.2 Wall-mounting Instructions
Complete the following steps to hang your ZyXEL Device on a wall.
"
See
for the size of screws to use and how far apart to
place them.
1 Select a position free of obstructions on a sturdy wall.
2 Drill two holes for the screws.
RoadRunner Support
The ZyXEL Device supports Time Warner’s RoadRunner Service in
addition to standard cable modem services.
Firewall
You can configure firewall on the ZyXEL Device for secure Internet
access. When the firewall is on, by default, all incoming traffic from the
Internet to your network is blocked unless it is initiated from your
network. This means that probes from the outside to your network are
not allowed, but you can safely browse the Internet and download files
for example.
Remote Management
This allows you to decide whether a service (HTTP or FTP traffic for
example) from a computer on a network (LAN or WAN for example) can
access the ZyXEL Device.
Table 121 Feature Specifications
FEATURE
SPECIFICATION
Local User Database Entries
32
Static DHCP Table Entries
32
Static Routes
30
Concurrent Sessions (NAT sessions)
3,000
Address Mapping Rules
10
Port Forwarding Rules
20
DNS Address Record Entries
30
DNS Name Server Record Entries
16
Firewall Throughput (with NAT)
12 Mbps
Output Power (Maximum)
IEEE 802.11b: 16 dBm at 11 Mbps CCK,
QPSK, BPSK
IEEE 802.11g: 13 dBm at 54 Mbps OFDM
Table 120 Firmware Specifications
FEATURE
DESCRIPTION
