Chapter 5 LAN Screens
NBG410W3G Series User’s Guide
110
"
Your changes are also reflected in the DMZ Port Roles screen.
Figure 69 NETWORK > LAN > Port Roles
The following table describes the labels in this screen.
After you change the LAN or DMZ port roles and click Apply, please wait for few seconds
until the following screen appears. Click Return to go back to the Port Roles screen.
Figure 70 Port Roles Change Complete
Table 15 NETWORK > LAN > Port Roles
LABEL DESCRIPTION
LAN Select a port’s LAN radio button to use the port as part of the LAN. The port will
use the ZyXEL Device’s LAN IP address and MAC address.
DMZ Select a port’s DMZ radio button to use the port as part of the DMZ. The port will
use the ZyXEL Device’s DMZ IP address and MAC address.
Apply Click Apply to save your changes.
Reset Click Reset to begin configuring this screen afresh.
