Chapter 6 WAN Screens
NBG410W3G Series User’s Guide
115
6.5 WAN IP Address Assignment
Every computer on the Internet must have a unique IP address. If your networks are isolated
from the Internet, for instance, only between your two branch offices, you can assign any IP
addresses to the hosts without problems. However, the Internet Assigned Numbers Authority
(IANA) has reserved the following three blocks of IP addresses specifically for private
networks.
Check Traffic
Redirection
Connectivity
Select the check box to have the ZyXEL Device periodically test the traffic redirect
connection.
Select Ping Default Gateway to have the ZyXEL Device ping the backup
gateway's IP address.
Select Ping this Address and enter a domain name or IP address of a reliable
nearby computer (for example, your ISP's DNS server address) to have the ZyXEL
Device ping that address. For a domain name, use up to 63 alphanumeric
characters (hyphens, periods and the underscore are also allowed) without
spaces.
Windows
Networking
(NetBIOS over
TCP/IP)
NetBIOS (Network Basic Input/Output System) are TCP or UDP packets that
enable a computer to connect to and communicate with a LAN. For some dial-up
services such as PPPoE or PPTP, NetBIOS packets cause unwanted calls.
Allow between
WAN1 and LAN
Select this check box to forward NetBIOS packets from WAN 1 to the LAN port and
from the LAN port to WAN1. If your firewall is enabled with the default policy set to
block WAN 1 to LAN traffic, you also need to enable the default WAN1 to LAN
firewall rule that forwards NetBIOS traffic.
Clear this check box to block all NetBIOS packets going from WAN 1 to the LAN
port and from LAN port to WAN1.
Allow between
WAN1 and DMZ
Select this check box to forward NetBIOS packets from WAN 1 to the DMZ port and
from the DMZ port to WAN1.
Clear this check box to block all NetBIOS packets going from WAN 1 to the DMZ
port and from DMZ port to WAN1.
Allow between
WAN2 and LAN
Select this check box to forward NetBIOS packets from WAN 2 to the LAN port and
from the LAN port to WAN2. If your firewall is enabled with the default policy set to
block WAN 2 to LAN traffic, you also need to enable the default WAN2 to LAN
firewall rule that forwards NetBIOS traffic.
Clear this check box to block all NetBIOS packets going from WAN 2 to the LAN
port and from LAN port to WAN2.
Allow between
WAN2 and DMZ
Select this check box to forward NetBIOS packets from WAN 2 to the DMZ port and
from the DMZ port to WAN2.
Clear this check box to block all NetBIOS packets going from WAN 2 to the DMZ
port and from DMZ port to WAN2.
Allow Trigger Dial Select this option to allow NetBIOS packets to initiate calls.
Apply Click Apply to save your changes.
Reset Click Reset to begin configuring this screen afresh.
Table 16 NETWORK > WAN General (continued)
LABEL DESCRIPTION
Table 17 Private IP Address Ranges
10.0.0.0 - 10.255.255.255
172.16.0.0 - 172.31.255.255
192.168.0.0 - 192.168.255.255
