Chapter 19 Logs Screens
NBG410W3G Series User’s Guide
308
Figure 190 LOGS > Reports
"
Enabling the ZyXEL Device’s reporting function decreases the overall
throughput by about 1 Mbps.
The following table describes the labels in this screen.
Table 91 LOGS > Reports
LABEL DESCRIPTION
Collect
Statistics
Select the check box and click Apply to have the ZyXEL Device record report data.
Send Raw
Traffic Statistics
to Syslog
Server for
Analysis
Select the check box and click Apply to have the ZyXEL Device send unprocessed
traffic statistics to a syslog server for analysis.
You must have the syslog server already configured in the Log Settings screen.
Apply Click Apply to save your changes to the ZyXEL Device.
Reset Click Reset to begin configuring this screen afresh.
Interface Select on which interface (LAN or DMZ) the logs will be collected. The logs on the
DMZ or LAN IP alias 1 and 2 are also recorded.
Report Type Use the drop-down list box to select the type of reports to display.
Web Site Hits displays the web sites that have been visited the most often from the
LAN and how many times they have been visited.
Protocol/Port displays the protocols or service ports that have been used the most
and the amount of traffic for the most used protocols or service ports.
Host IP Address displays the LAN or DMZ IP addresses to and /or from which the
most traffic has been sent and how much traffic has been sent to and from those IP
addresses.
Refresh Click Refresh to update the report display. The report also refreshes automatically
when you close and reopen the screen.
Flush Click Flush to discard the old report data and update the report display.
