9: Debugging Your System
ARM720T CORE CPU MANUAL EPSON 9-31
9.18.3 Watchpoint with another exception
If a watchpointed access simultaneously causes a Data Abort, the ARM720T processor enters
debug state in abort mode. Entry into debug is held off until the core changes into abort mode
and has fetched the instruction from the abort vector.
A similar sequence follows when an interrupt, or any other exception, occurs during a
watchpointed memory access. The ARM720T processor enters debug state in the mode of the
exception. The debugger must check to see whether an exception has occurred by examining
the current and previous mode (in the CPSR, and SPSR), and the value of the PC. When an
exception has taken place, you are given the choice of servicing the exception before
debugging.
Entry to debug state when an exception has occurred causes the PC to be incremented by three
instructions rather than four, and this must be considered in return branch calculation when
exiting debug state. For example, suppose that an abort occurs on a watchpointed access, and
ten instructions have been executed to determine this eventuality. You can use the following
sequence to return to program execution.
0 E1A00000 ; MOV R0, R0
1 E1A00000 ; MOV R0, R0
0 EAFFFFF0 ; B -16
This code forces a branch back to the abort vector, causing the instruction at that location to
be refetched and executed.
Note:
After the abort service routine, the instruction that caused the abort, and
watchpoint is refetched and executed. This triggers the watchpoint again and the
ARM720T processor reenters debug state.
9.18.4 Debug request
Entry into debug state using a debug request is similar to a breakpoint. However, unlike a
breakpoint, the last instruction has completed execution and so must not be refetched on exit
from debug state. Therefore, you can assume that entry to debug state adds three addresses
to the PC and every instruction executed in debug state adds one address.
For example, suppose you have invoked a debug request, and decide to return to program
execution straight away. You could use the following sequence:
0 E1A00000 ; MOV R0, R0
1 E1A00000 ; MOV R0, R0
0 EAFFFFFA ; B -6
This code restores the PC and restarts the program from the next instruction.
9.18.5 System speed access
When a system speed access is performed during debug state, the value of the PC increases by
three addresses. System speed instructions access the memory system and so it is possible for
aborts to take place. If an abort occurs during a system speed memory access, the ARM720T
processor enters abort mode before returning to debug state.
This scenario is similar to an aborted watchpoint, but the problem is much harder to fix
because the abort was not caused by an instruction in the main program, and so the PC does
not point to the instruction that caused the abort. An abort handler usually looks at the PC to
determine the instruction that caused the abort and also the abort address. In this case, the
value of the PC is invalid, but because the debugger can determine which location was being
accessed, the debugger can be written to help the abort handler fix the memory system.
