48 5 Programming: Tools
5.2 T
ool D
a
ta
Tool table: Tool data required for automatic tool measurement
Abbr. Input
CUT. Number of teeth (20 teeth maximum)
LTOL Permissible deviation from tool length L for
wear detection. If the entered value
is exceeded, the TNC locks the tool(status L).
Input range: 0 to 0.9999 mm
RTOL Permissible deviation from tool radius R for
wear detection. If the entered value
is exceeded, the TNC locks the tool(status L).
Input range: 0 to 0.9999 mm
DIRECT. Cutting direction of the tool for measuring the tool
during rotation
TT:R-OFFS Tool length measurement: tool offset between
stylus center and tool center. Preset value:
R = Tool radius R
TT:L-OFFS Tool radius measurement: tool offset in addition
to MP6530
(see section 15.1 +General User Parameters+)
between upper edge of stylus and lower edge of tool.
Preset value: 0
LBREAK Permissible deviation from tool length L for
breakage detection. If the entered value is exceeded,
the TNC locks the tool (status L).
Input range: 0 to 0.9999 mm
RBREAK Permissible deviation from tool radius R for breakage
detection. If the entered value is exceeded,
the TNC locks the tool(status L).
Input range: 0 to 0.9999 mm
Dialog
Number of teeth ?
Wear tolerance: length ?
Wear tolerance: radius ?
Cutting direction (M3 = –) ?
Tool offset: radius ?
Tool offset: length ?
Breakage tolerance: length ?
Breakage tolerance: radius ?
