217 HEIDENHAIN TNC 410
1
0.7 A
dditional F
unctions
Group name, ID No. Number Index System data
Limit switch, 230 1 – Number of the active limit switch range
2 1 to 4 Negative coordinate limit switch in M91 system
Index 1 to 4: X-axis to IVth axis
3 1 to 4 Positive coordinate limit switch in M91 system
Index 1 to 4: X-axis to IVth axis
Positions in M91 system, 240 1 1 to 4 Nominal position; Index 1 to 4: X-axis to IVth axis
2 1 to 4 Last touch point
Index 1 to 4: X-axis to IVth axis
3 1 to 4 Active pole; Index 1 to 4: X-axis to axis IV axis
4 1 to 4 Center point of circle; Index 1 to 4: X-axis to IVth axis
5 1 to 4 Center point of circle for the last RND block
Index 1 to 4: X-axis to IVth axis
Positions in the input system, 270 1 1 to 4 Nominal position; Index 1 to 4: X-axis to IVth axis
2 1 to 4 Last touch point
Index 1 to 4: X-axis to IVth axis
3 1 to 4 Active pole; Index 1 to 4: X-axis to axis IV axis
4 1 to 4 Center point of circle; Index 1 to 4: X-axis to IVth axis
5 1 to 4 Center point of circle for the last RND block
Index 1 to 4: X-axis to IVth axis
TT 120 calibration data, 350 20 1 Center of probe contact in X-axis
2 Center of probe contact in Y-axis
3 Center of probe contact in Z axis
21 – Probe contact radius
Example: Assign the value of the active scaling factor for the Z axis
to Q25.
55 FN18: SYSREAD Q25 = ID210 NR4 IDX3
